< Back to laser gain modules

NDYAG-QCW16-72-9

Designed for MOPA build and cascade amplification systems.

1064nm
WL
QCW
Mode
16.5kW
Peak pump
0.3ms
Pulse length
1.7J
Pulse energy
Request Price Request Price

Description

The module is designed to be used as a part of generator in an intracavity application, as well as an amplifier for an extracavity application.

Specification

Model NDYAG-QCW16-72-9
Rod material Nd:YAG
Rod concentration 0.6%
Rod diameter 9mm
Rod length 180mm
Operation mode QCW
Peak pump power >16.5kW
Small Signal Gain 12.5

Small signal gain

Input energy: 1.1 mJ
Current min-max: 40-220A (step 20A)
Pump pulse duration: 0.3 ms
Repetition rate: 10 Hz
